OVERVIEW

Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance

ECO Mode
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection

LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms.

Rack/Tower convertible
Protects the initial investment in the UPS when migrating from tower to rack-mount environment.

SPECIFICATIONS

Basic
Backup/Run Time (Full Load): 31.60 Minute
Brand Name: APC by Schneider Electric
Form Factor: Tower/Rack Mountable
Hot Swappable: Yes
Input Voltage Range: 80 V AC - 150 V AC
Input Voltage: 230 V AC
Load Capacity (VA): 1 kVA
Load Capacity (Watt): 900 W
Network (RJ-45): Yes
Plug/Connector Type: IEC 60320 C14
Product Family: Smart-UPS SRT
Product Type: Dual Conversion Online UPS
Rack Height: 3U
Receptacles: 8 x IEC 60320 C13
Waveform Type: Sine Wave

Battery Information
Backup/Run Time (Full Load): 31.60 Minute
Hot Swappable: Yes
Maximum Battery Recharge Time: 6 Hour

Interfaces/Ports
Network (RJ-45): Yes

Physical Characteristics
Depth: 590 mm
Form Factor: Tower/Rack Mountable
Height: 128 mm
Rack Height: 3U
Weight (Approximate): 25.70 kg
Width: 432 mm

Power Description
Input Voltage Range: 80 V AC - 150 V AC
Input Voltage: 230 V AC
Load Capacity (VA): 1 kVA
Load Capacity (Watt): 900 W
Output Voltage: 220 V AC
Waveform Type: Sine Wave

Technical Information
Plug/Connector Type: IEC 60320 C14
Receptacles: 8 x IEC 60320 C13
