• High-Speed Wi-Fi – Stream with fast and stable connections, reaching speeds up to 1167 Mbps (300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band)
• 4 High-Gain External Antennas – Receive strong Wi-Fi signals in every corner of your home
• Easy Installation – Set up in minutes guided by an intuitive web UI
• Active Parental Controls – Protect your family by setting appropriate access policies for responsible, safe internet use
• IPTV and IPv6 Supported

Specifications

Wireless Standards and Frequencies

• Wireless Standards:
  • IEEE 802.11ac/n/a (5 GHz band)
  • IEEE 802.11b/g/n (2.4 GHz band)
• Frequencies:
  • 2.4 GHz
  • 5 GHz

Signal Rate

• 2.4 GHz Band: Up to 300 Mbps
• 5 GHz Band: Up to 867 Mbps

Reception Sensitivity

• 2.4 GHz Band:
  • 11g 6Mbps: -96dBm
  • 11g 54Mbps: -78dBm
  • 11n HT40 MCS7: -74dBm
  • 11n HT20 MCS7: -71dBm
• 5 GHz Band:
  • 11a 6Mbps: -97dBm
  • 11a 54Mbps: -79dBm
  • 11ac VHT20 MCS8: -74dBm
  • 11ac VHT40 MCS9: -70dBm
  • 11ac VHT80 MCS9: -65dBm

Transmission Power

• 2.4 GHz: < 20dBm (EIRP)
• 5 GHz: < 23dBm (EIRP)

Wireless Security

• WEP
• WPA / WPA2
• WPA-PSK / WPA2-PSK

Wireless Functions

• Enable/Disable Wireless Radio
• WMM (Wi-Fi Multimedia)

Hardware Specifications

• Dimensions: 4.5 × 3.7 × 1.0 inches (114 × 94 × 26 mm)
• Button: Reset/WPS Button
• External Power Supply: 9V/0.85A
• Antenna Type: 4× 5 dBi Fixed Omni-Directional Antennas

Ethernet Ports

• WAN Port: 1× 10/100 Mbps
• LAN Ports: 2× 10/100 Mbps
