Ubiquiti UniFi 24 Ports Managed Gigabit Switch, PoE+
UbiquitiSKU: USW-24-POE
Ubiquiti UniFi 24 Ports Managed Gigabit Switch, PoE+
UbiquitiUbiquiti UniFi 24 Ports Managed Gigabit Switch, PoE+
SKU:USW-24-POE
Prix habituel
6 963 Dhs
Prix habituel
0 Dhs
Prix promotionnel
6 963 Dhs
Quantité
Contactez-nous
Frais d'expédition calculés à l'étape de paiement.
Livraison gratuite nationale pour toute commande supérieure à 1500 Dhs
- Garantie 7 jours retours
- Commandez avant 12h00 pour une expédition sous 24h
- Paiement à la livraison
Overview
A 24-port, Layer 2 PoE switch with a fanless cooling system.
- (16) GbE PoE+, (8) GbE ports
- (2) 1G SFP ports
- 95W total PoE availability
- Fanless, silent cooling
Specifications
A 24-port, Layer 2 PoE switch with a fanless cooling system.
- (16) GbE PoE+, (8) GbE ports
- (2) 1G SFP ports
- 95W total PoE availability
- Fanless, silent cooling
Specifications
| Mechanical | |
|---|---|
| Dimensions | 442 x 200 x 44 mm (17.4 x 7.9 x 1.7") |
| Weight | Without mounting brackets: 3 kg (6.6 lb) With mounting brackets: 3.1 kg (6.8 lb) |
| Enclosure material | SGCC steel |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (24) GbE RJ45 ports (2) 1G SFP ports |
| PoE interface | (16) PoE/PoE+ (Pins 1, 2+; 3, 6-) |
| Total non-blocking throughput | 26 Gbps |
| Switching capacity | 52 Gbps |
| Forwarding rate | 38.69 Mpps |
| Power method | Universal input, 100—240V AC, 50/60 Hz |
| Power supply | AC/DC, internal, 120W |
| Supported voltage range | 100—240V AC |
| Max. power consumption | 25W (Excluding PoE output) |
| Total available PoE | 95W |
| Max. PoE wattage per port by PSE | PoE+: 32W |
| Voltage range PoE mode | PoE: 44—57V PoE+: 50—57V |
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV |
| LCM display | (1) 1.3" touchscreen |
| Button | Factory reset |
| Shock and vibration | ETSI300-019-1.4 Standard |
| Operating temperature | -5 to 40° C (23 to 104° F) |
| Operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | PoE Speed/link/activity |
| SFP | Link/activity |
| Application Requirements | |
| UniFi Network | Version 7.2.94 and later |
